Quick Details

  • Type: parking system
  • Height (mm): vehicle length 5000
  • Width (mm): vehicle width 1900
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Tada
  • Model Number: PSH5D-2-LT
  • Warranty: 1 Years

Packaging & Delivery

Packaging Details Standard export packing
Delivery Time 30-120 days after receiving the deposit

PSH Parking Lift Type puzzel parking system/car garage lift for basement



1.Advantage and Application

(1)This type of parking equipment has a lot of combinations much adaptable for different sites and with low civil requirements.

(2)You can combine freely according to different space and terrain.

(3)Its maintenance is simple and low-cost.

(4)You can fix it in the open air, basement, on the ground, and underground.



2.Equipment Formation

Each controlling group of this parking system can be designed from 3-car to 10-car and can also be arranged into tandem columns. The best option is within 17 cars per group, and its up to the specific site conditions.



3.Working Principle

The equipment uses chain or wire to lift and utilizing big span design in front or back side, each parking space with a car board, which through lifting up and down and sliding to the ground, the driver goes into the garage, parks or takes a car, finishes the whole procedure.



4.Equipment Type

4-point safety device on the ground and underground; independent car-resistant device, over-length, over-range and over-time detection secure the safety of cars.



5.Technical Parameters

No.

Name

Instruction

1

Layer

Upper layer

Ground layer

2

Vehicle Size

Length

5000(mm)

5000(mm)

Width

1850(mm)

1900(mm)

Height

1550(mm)

1550(mm)

3

Vehicle Weight

1700(kg)

2000(kg)

4

Lifting

Power

2.2(kw)

Speed

4(m/min)

5

Sliding

Power

0.2(kw)

Speed

8(m/min)

6

Driven Mode

Motor+Chain

7

Operation Mode

Button, Automatic, Manual

8

Power Supply

AC380V/220V50Hz; 3¢380V/220V50Hz
